What could the best aluminum alloy road wheels look like? Light but durable, laterally stiff but vertically flexible, reliable braking and simple tubeless compatibility: that's the all-new Ksyrium SL Disc.

• Compatibility
• Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters (not available in Germany)
• Front axle: convertible from 12mm thru axle to quick release or 15mm thru axle with optional adapters
• Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
• Weight
• Tyre 700x25: 210 grams
• Pair without tyre: 1670 grams
• Front without tyre: 770 grams
• Rear without tyre: 900 grams
• Hubs
• Front : adjustable sealed cartridge bearings (QRM+), Rear : auto adjust sealed cartridge bearings (QRM Auto)
• Freewheel: Instant Drive 360
• Front and rear bodies: aluminum
• Axle material: aluminum
• Intended Use
• For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
• ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
• Max. Pressure tubeless: 25mm 6 bars - 87 PSI, 28mm 5 bars - 70 PSI. Max pressure tubetype: 25/28mm 7,7 bars - 110 PSI
• Recommended tyre sizes: 25 to 32 mm
• Rims
• Height: 22 mm
• ETRTO size: 622x19TC Road
• Use with Mavic Tubeless Tape
• Weight reduction: ISM 4D
• Internal width: 19 mm
• Disc brake specific profile
• Valve hole diameter: 6.5 mm
• Tyre: UST Tubeless and tubetype
• Drilling: Fore
• Joint: SUP
• Material: Maxtal
• Spokes
• Material: steel
• Shape: straight pull, bladed
• Lacing: front crossed 2, rear Isopulse
• Nipples: Fore integrated aluminum
• Count: 24 front and rear
• Tyre
• Front and Rear Tread: 11 Storm single compound
• Yksion Pro UST
• UST Tubeless Ready
• Dimension: 25-622 (700x25c)
• Breaker: Polyamide, from bead to bead
• Casing: 127 TPI
• Versions
• Disc standard : 6 Bolts or Center Lock(R)
• Color: Black only
• Delivered with
• Front 12 mm adapters
• Rear 12x142mm adapters for Instant Drive 360
• Mavic tyre sealant (rear wheel)
• Specific disc bolts
• UST valve and accessories
• User guide
