The Marlin 5 is a great ride for all your adventures. It's also versatile and a popular ride on college campuses because the rack and kickstand mounts make it easy to accessorise and haul a load.
- *Frame Size: XXS , XS
- Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
- Size: S , M , ML , L , XL , XXL
- Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
- *Fork Size: XXS
- SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 26'' wheel, 100 mm QR, 100 mm travel
- Size: XXS
- SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel, 26" wheel
- Size: XS
- SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
- Size: S
- SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
- Size: M , ML , L , XL , XXL
- SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
- Max compatible fork travel 120mm, XXS: 80mm
- Wheels
- Hub front Formula DC-20, alloy, 6-bolt, 5x100 mm QR
- Hub rear Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
- Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- *Tyre Size: XXS
- Bontrager XT3 Comp, wire bead, 30 tpi, 26x2.35"
- Size: XS , S
- Bontrager XT3 Comp, wire bead, 30 tpi, 27.5x2.40"
- Size: M , ML , L , XL , XXL
- Bontrager XT3 Comp, wire bead, 30 tpi, 29x2.40"
- Max tyre size Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer
- Drivetrain
- Shifter Shimano U4000, 9-speed
- Rear derailleur Shimano CUES U4000
- *Crank Size: XXS , XS
- Prowheel C10Y-NW, 30T steel narrow-wide ring, 160 mm length
- Size: S , M , ML , L , XL , XXL
- Prowheel C10Y-NW, 30T steel narrow-wide ring, 170 mm length
- Cassette Shimano LINKGLIDE LG300, 11-46, 9-speed
- Chain Shimano LG500
- Pedal VP-536 nylon platform
- Max. chainring size 1x: 34T, 2x: 36/22
- Components
- *Seatpost Size: XXS
- Bontrager alloy, 31.6 mm, 12 mm offset, 300 mm length
- Size: XS , S , M
- Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
- Size: ML , L , XL , XXL
- Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
- *Handlebar Size: XXS , XS
- Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
- Size: S
- Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
- Size: M , ML , L , XL , XXL
- Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
- Grips Bontrager XR Trail Comp, nylon lock-on
- *Stem Size: XXS , XS , S
- Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length
- Size: M , ML , L
- Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
- Size: XL
- Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
- Size: XXL
- Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
- Head set Semi-integrated, 1-1/8"
- Brake rotor Tektro, 6-bolt, 160mm
- *Brake Set Size: XXS , XS , S
- Tektro HD-M276 hydraulic disc, short reach
- Size: M , ML , L , XL , XXL
- Tektro HD-M275 hydraulic disc
- Rotor size Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer
2019
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- The Marlin Gen 3 gives you serious trail capability, with big tyre clearance and slack, confidence-boosting geometry that keeps you stable from singletrack to city
- Rack and mudguard mounts make it easy to accessorise, so your mountain bike can double as a rugged commuter
- Its ThruSkew system is safer, simpler and stronger, plus it makes removing the rear wheel easy for flat fixes in a hurry
- Internal routing makes it easy to add a dropper post that lets you lower your saddle on the fly for more confident descending
- Marlin models in sizes XXS and XS have a curved top tube and lower standover height that makes it easier for smaller riders to mount and dismount
|
|
|
|
|
|
|
|
|
