Combining best-in-class stiffness-to-weight with strategically placed aero tube shaping, this frameset is engineered for faster climbing, explosive acceleration and unyielding pedaling stiffness for race-winning performance.
- SizesS, M, M/L, L, XL
- ColoursGloss Helios Orange/Shoreline
- FrameAdvanced-grade composite, disc
- ForkAdvanced-grade composite, full-composite OverDrive steerer, disc
- ShockN/A
- HandlebarGiant Contact S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
- GripsStratus Lite 2.0
- StemGiant Contact S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
- SeatpostGiant Variant, composite, -5/+15mm offset
- SaddleGiant Approach
- PedalsN/A
- ShiftersShimano 105 Di2 2x12
- Front DerailleurShimano 105 Di2
- Rear DerailleurShimano 105 Di2
- BrakesShimano 105 Di2 hydraulic, Shimano SM-RT70 rotors [F]160mm, [R]140mm
- Brake LeversShimano 105 Di2
- CassetteShimano 105, 12-speed, 11x34
- ChainKMC X12L-1
- CranksetShimano 105, 36/52 S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
- Bottom BracketShimano, press fit
- RimsGiant SLR 2 36 Carbon Disc WheelSystem, [F] 36mm, [R] 36mm
- Hubs[F] Giant alloy, CenterLock, 12mm thru-axle [R] Giant alloy, 3-pawl 30t driver, CenterLock, 12mm thru-axle
- SpokesSapim Sprint
- TyresGiant Course 1, tubeless, 700x25c (28mm), folding
- Extrasfactory tubeless set up, 32mm max tyre size
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Advanced aerodynamics
- This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.
- Total control
- Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allow
|
|
|
|
|
|
|
|
|
